SpeedBox 3.2 for Specialized Gen4 3.1 Motor

Maximum speed: unlimited
Speed limit setting: YES
Display shows: actual values
Activation: By pressing the WALK button or - + - +
Compatible with motors:
Specialized 3.1 (101 Nm)
Specialized 3.1 S-Works (111 Nm)
Not compatible with: SpeedBox App

What does this Tuning Kit do?

SpeedBox 3.2 deactivates the speed limit of the e-bike, allowing you to enjoy riding at unlimited speed. After installing the chip, the e-bike display shows real data such as maximum or average speed, daily distance, and range.

How does SpeedBox 3.2 work?

The tuning kit manipulates the speed signal without altering the motor's power relative to pedaling speed. This guarantees a smooth motor control without speed limit interruptions. Depending on a tuning kit, some determine when assistance stops, while others remove the restriction entirely for continuous support. However, the achievable speed mostly depends on the eBike model. Achievable speed can be calculated using a simple formula:

Speed = Cadence [rpm] * Wheel circumference [mm] * Front Chainring Teeth / Rear Chainring Teeth * 60 [min/h] / 1.000.000 [mm/km]

You activate the tuning by pressing the WALK button or using the button combination - + - +. The value 35.1 km/h will briefly appear on the display, indicating the preset maximum speed of 35 km/h.

You deactivate the tuning in the same way. The value 25 km/h will appear on the display and the e-bike will then work the same as before installing the tuning.

You can change the maximum assist speed by switching the modes from TRAIL three levels down and then three levels up (AUTO - ECO - OFF - ECO - AUTO - TRAIL). The default maximum assist speed will appear on the display. Each time you press the WALK button or rotate the rear wheel, the maximum assist speed increases by 5 km/h. The last displayed limit will be saved after five seconds of inactivity.

Which Speedbox Tuning Kit do I need?

Compatible with motors:

Specialized GEN 4 (3.1/S-Works) Only

Not compatible with: SpeedBox App

How to install this Tuning kit?

Video - https://www.youtube.com/watch?v=d4M8k6EF1AE

Important legal note!

Please note that the operation of this type of modified electric bikes on public roads may be against the law in some countries. The manufacturer takes no responsibility for damages resulting from the use SpeedBox products. Electric bikes equipped with SpeedBox products are not allowed to be used on public roads, cycling paths and public places. Electric bikes equipped with SpeedBox products can be used exclusively on private property and entirely at one’s own risk.

The use of SpeedBox may void the warranty of your ebike.We strongly recommend using other safety features and protective gear to prevent injuries in higher speeds.

SpeedBox Products are thoroughly tested and we stand by their quality. SpeedBox provide Life Long warranty to all their Products!

If You have any questions, please do not hesitate to contact us. Thank you for looking! Two Wheels Empire Team
